Coaxial cable cutting and Stripping Machine WPM-9600S
Coaxial cable cutting and Stripping Machine WPM-9600S
  • Coaxial cable cutting and Stripping Machine WPM-9600S

  • item No : WPM -9600S
  • Automatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine
    wire capability OD:0.80-5.5mm
    The maximum Strip:Left  end:40(mm)  Right end (unlimited)
    Maximum strip layers:4 layers
    Power supply:220V/50HZ   P:380W
    Cutting off length:70mm-9999mm
    The material range: Coaxial cable
    Store data:60 parameters can be stored in procedures
    Drive mode: Motor, ball screw drive

  • Inquiry now
Detailed description

Coaxial cable cutting and Stripping Machine WPM-9600S
Automatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping Machine
 The characteristics explain:
mainly used for coaxial cable and special radix wire transform, choose the most advanced revolution rest, raised accuracy and velocity, adopt the particular axis clamping device and gyration tool angel method, the maximum could shell 9 F has never needed to replace knife blade to then liberalizing to establish to make controller towards the process to correspond the size and cortex electric wire, and equipping canning and incise wire diameter through a figure display.

Machinery specification:

Model

WPM -9600S

wire capability OD

0.80-5.5mm

The maximum Strip

Left  end:40(mm)  Right end (un-limited)

Maximum strip layers

4 layers

Power supply

220V/50HZ   P:380W

Cutting off length

70mm-9999mm

The material range coaxial

Coaxial cable

Store data

60 parameters can be stored procedures

Drive mode

Motor, ball screw drive

Knife blade

2 pcs of the rotating cutter, material: tungsten steel material peeling blades 4 pcs high-speed steel

Productivity

500-700pcs/h





Power supply

220V/50HZ   P:380W

Weight

100(kg)

Features size

800*700*440mm

Working condition

0-50 degrees, the drying degree is just right, have no dither of  workbench surface,

drying degree just right workshop

 Automatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping MachineAutomatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping MachineAutomatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping Machineapplications of Automatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping Machineapplications of Automatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, Automatic Coaxial Cable Wire Stripping MachineAutomatic Coaxial cable cutting stripping machine, Cable Stripping Machine, Coaxial Cable Stripping Machine, Stripping Machine, Flexible Coaxial Wire Peeling Machine, Coaxial Wire Cutting Peeling Machine, AutomatApplications of Coaxial Cable Wire Stripping Machine
