Model |
WPM-09D |
WPM-09JE |
WPM-09JE |
|
Wire material |
PVC, teflon, fiberglass wire... |
PVC, teflon, fiberglass wire... |
PVC, teflon, fiberglass wire... |
|
Conductor cross-section |
0.1 - 8.0 mm² (32 - 8 AWG) |
0.1 - 8.0 mm²(32 - 8 AWG) |
0.1 - 10 mm²(32 - 7 AWG) |
|
Cutting length |
1 - 99,999 mm |
1 - 99,999 mm |
1 - 100,000 mm |
|
Cutting length tolerance |
0.002 * L |
0.002 * L |
0.002 * L |
|
Stripping length |
Side I: 0 - 35 mm Side II: 0 - 15 mm |
Side I: 0-50mm Side II: 0 - 50 mm |
Side I: 0 - 80 mm Side II: 0 - 80 mm |
|
Maximum guide tube diameter |
8 - 10 mm |
8 - 10 mm |
13 mm |
|
Productivity |
33 - 83pcs/min |
33-83pcs/min |
50-133pcs/min |
|
Noise level |
< 70 dB(A) |
< 70 dB(A) |
< 70 dB(A) |
|
Power supply |
110, 220 V (50 - 60 Hz) |
110, 220 V (50 - 60 Hz) |
110, 220 V (50 - 60 Hz) |
|
Power |
300 W |
300 W |
500 W |
|
Gross Weight |
34 kg |
34 kg |
34 kg |
|
Carton dimension |
537 * 507 * 400 mm |
537 * 507 * 400 mm |
537 * 507 * 400 mm |
